Cylinder Liner Performance O/S 1.3 mm OD + 1.0 mm O/S flange OD, semi-finished

1.3 mm oversize OD & 1.0 mm oversize flange OD liner to suit Nissan TD42 series. If the engine has been overheated, the engine block parent bores are probably out of round & distorted. If the block is very badly distorted or the engine is being built for performance operation, then this heavy wall liner should be used. All bores should be repaired, and boring and honing the block must be done with the main caps fitted and bolts tensioned to specification. OD 100.32 mm, Flange OD 106 mm, Flange Height 5 mm, Length 164 mm, ID 95.8 mm Semi-Finished. Bore requires honing.  (DPP brand - made in Taiwan)
