Timing Chain Tensioner Slipper (Cam)
Camshaft Timing Chain Tensioner Slipper to suit Toyota 1GD-FTV & 2GD-FTV engines. (Genuine)
$76.46 inc. GST
Timing Chain, Tensioner and Guide Kit
Timing Chain, Tensioner and Guide Kit to suit Nissan ZD30DDT and ZD30DDTi engines.
$200.20 inc. GST
Timing Chain, Tensioner and Guide Kit
Timing Chain, Tensioner and Guide Kit to suit Nissan ZD30DDTiCFR engines.
(OSK brand)
May also rerquire Cam Chain Drive Sprocket (TGNI202) and Cam Chain Sprocket (TGNI202A)
$200.20 inc. GST
Timing kit – Simplex
Simplex timing kit to suit Ford DT32 / Mazda P5AT (all)
The injector pump gear is NOT included in our kit.
Injector pump gear on the Ford version changes from 15/09/15. It becomes tapered with a keyway and has a counterweight.
Genuine gears are available as separate item if required.
Ford Ranger up to 14/09/'15 and Mazda BT50 - IPGFO105
Ford 15/09/'15 onwards - IPGFO105A
$777.70 inc. GST inc. GST
Timing Kit – Performance Duplex
Performance Duplex Timing Sprocket, Guide, Tensioner and Chain Kit for Ford Ranger PX DT32 (up to 14/9/2015) and Mazda BT50 P5AT (all).
If you have increased the power of your engine, then you are placing all your internal engine components under increased stress and strain. The timing chains carry all the force for driving the camshafts and injection pump from the crankshaft. By using a dual row chain and sprockets, you significantly increase the loads they can withstand before stretching or even failure. When you are replacing your timing chains, guides, sprockets and tensioner, invest in security with one of our upgraded Diesel Performance Parts Duplex Timing kits.
Note: DOES NOT SUIT FORD RANGER 15/09/15 ONWARDS. Injector pump gear on the Ford version changes from 15/09/15. It becomes tapered with a keyway and has a counterweight.
$930.00 inc. GST inc. GST
Timing, Injector Pump and Cam Sprocket Kit
Injector Pump and Cam Sprocket Kit to suit Nissan ZD30DDT and ZD30DDTi engines.
(DPP brand)
$92.09 inc. GST
TOTAL SEAL Quick Seat Dry Assembly Lube (14 gm container)
Quick Seat is a dry film lubricant engineered by Total Seal with a blend of compounds to minimise or even eliminate scuffing and micro-welding of ring faces to bores during initial start-up.
It promotes:
- Quicker ring seating
- Longer ring life
- Reduced blow-by
An added benefit is that when applied to bores it will give them a greenish tint if they are clean, but black or a silverish colour if the crosshatch is still dirty.
(14 gm container)
$231.00 inc. GST
TOTAL SEAL Quick Seat Dry Assembly Lube (2 gm container)
Quick Seat is a dry film lubricant engineered by Total Seal with a blend of compounds to minimise or even eliminate scuffing and micro-welding of ring faces to bores during initial start-up.
It promotes:
- Quicker ring seating
- Longer ring life
- Reduced blow-by
An added benefit is that when applied to bores it will give them a greenish tint if they are clean, but black or a silverish colour if the crosshatch is still dirty.
(2 gm container)
$73.92 inc. GST
TOYOTA 1H SERIES HI-FLOW FAN AND HUB KIT (32MM ADAPTER)
Hi-Flow Fan and Hub Kit to suit Toyota 1HZ, 1HZ-T, 1HD-T, 1HD-FT AND 1HD-FTE engines. This kit includes the fan and viscous hub (bolted together), viscous hub to water pump pulley adaptor (32 mm long) and all bolts required for installation. In-house testing on three different vehicles saw up to 4 - 8°C drop in engine cooling system temperatures across the radiator with back-to-back testing of the standard fan and viscous hub compared to the Diesel Performance Parts hi-flow fan and viscous hub. Under some conditions the drop was even higher.
Click this link to determine which kit suits your vehicle
Click this link to view article relating to 1HZT overheating problems
$495.00 inc. GST
TOYOTA 1H SERIES HI-FLOW FAN AND HUB KIT (42.5MM ADAPTER)
Hi-Flow Fan and Hub Kits to suit Toyota 1HZ, 1HZ-T, 1HD-T, 1HD-FT AND 1HD-FTE engines. This kit includes the fan and viscous hub (bolted together), viscous hub to water pump pulley adaptors (42.5 mm long) and all bolts required for installation. In-house testing on three different vehicles saw from 4 - 8°C drop in engine cooling system temperatures across the radiator with back-to-back testing of the standard fan and viscous hub compared to the Diesel Performance Parts hi-flow fan and viscous hub. Under some conditions the drop was even higher.
Click this link to determine which kit suits your vehicle
Click this link to view article relating to 1HZT overheating problems
$495.00 inc. GST
TOYOTA 1HD-FT & FTE PERFORMANCE EXHAUST VALVE
Performance exhaust valve to suit Toyota 1HD-FT & FTE engines.
Diesel Performance Parts valves are designed and manufactured for high performance diesel applications. The valve bodies are one-piece forgings made of 21-4N stainless steel and the stem ends are tipped with induction hardened 4Cr9Si2 friction welded, steel wafers. The exhaust valve faces are Stellite welded, and all valve bodies are fully Nitride hardened. The valve heads are fully machined, and the underside radii are swirl polished right to the valve face to promote better air flow and combustion chamber swirl. Both valves have a 30° back-cut up to the 45° valve faces. The valve body and valve face metals have been selected and prepared to withstand high temperature conditions, high stress applications and highly corrosive combustion chamber atmospheres – the standard environment for a high-performance diesel engine. These valves are best matched with our specially manufactured high performance valve seat inserts.
(Diesel Performance Parts brand - made in Taiwan)
$43.12 inc. GST inc. GST
TOYOTA 1HD-FT & FTE PERFORMANCE INLET VALVE
Performance inlet valve to suit Toyota 1HD-FT & FTE engines.
Diesel Performance Parts valves are designed and manufactured for high performance diesel applications. The valve bodies are one-piece forgings made of 21-4N stainless steel and the stem ends are tipped with induction hardened 4Cr9Si2 friction welded, steel wafers. The exhaust valve faces are Stellite welded, and all valve bodies are fully Nitride hardened. The valve heads are fully machined, and the underside radii are swirl polished right to the valve face to promote better air flow and combustion chamber swirl. Both valves have a 30° back-cut up to the 45° valve faces. The valve body and valve face metals have been selected and prepared to withstand high temperature conditions, high stress applications and highly corrosive combustion chamber atmospheres – the standard environment for a high-performance diesel engine. These valves are best matched with our specially manufactured high performance valve seat inserts.
(Diesel Performance Parts brand - made in Taiwan)
$33.88 inc. GST inc. GST
Turbocharger Mounting Gasket Kit
Turbocharger mounting gasket kit to suit Nissan TD42T/Ti. Includes gaskets and washers required to replace the turbocharger. (DPP brand - made in Taiwan)
$86.24 inc. GST
Turbocharger standard replacement – wet, hi-flow
Replacement HT18 turbocharger for the standard non-intercooled (wet) TD42T turbocharger. This unit is a hi-flow version of the standard turbocharger, with larger turbine and compressor wheels. This turbocharger with other supporting modifications and tuning can increase power by 30 - 35% over the standard turbocharger. This price includes a $500 core charge that is refunded when the old turbocharger is returned unopened. (DTS brand) EXCHANGE
$P.O.A
Vacuum Pump 1H Series
Diesel Power Parts Toyota 1H series Vacuum Pump. Suits 1HZ / 1HZT / 1HDT / 1HDFT / 1HDFTE engines. Delivers 0.7 to 0.9 bar (10 to 13 psi). Includes mounting o-ring. OE reference 29300-17010.
(DPP brand)
$223.30 inc. GST
Valve Guide
Inlet and Exhaust valve guide to suit Toyota 1VD-FTV engines. This valve guide can be purchased individually. 4 required per cylinder. (DPP brand - made in Taiwan)
$2.77 inc. GST
Valve Collet (Pair)
Valve Collet (Pair) to suit Nissan ZD30DDT, ZD30DDTi and ZD30 DDTiCFR engines.
(Genuine)
$2.70 inc. GST
Valve Exhaust
Standard replacement exhaust valve to suit Toyota 1VD-FTV engines. Austenitic, welded tip, nitrided. Head diameter 26.80 - 27.00 mm, length 103.95 - 104.15 mm, stem diameter 5.960 - 5.975 mm. 2 required per cylinder.
This valve can be purchased individually.
(DPP brand - made in Taiwan)
$18.48 inc. GST
Valve Guide
Valve Guide to suit Nissan ZD30DDT, ZD30DDTi and ZD30 DDTiCFR engines.
(DPP brand)
$4.31 inc. GST
All prices include GST
